Open Top – Cone Bottom Batch Tanks are designed for indoor applications. Perfect for batch
chemical/mixer mounting systems as well as many other applications. All tanks feature 8″ lids and one standard fitting. Cone Bottom tanks require the use of a stand for support. Both polyethylene and metal stands are available. Open Top – Cone Bottom Batch Tanks come standard with bolt-on lid, a polyethylene hinged lid option is also available. Tanks are manufactured from medium-density polyethylene with U.V. inhibitors and are designed for the containment of liquids up to 2.0 specific gravity. Tank walls are translucent for level viewing and equipped with liter and gallon indicators.
| Part No. | Capacity | Weight | Dimensions | Lid | Fitting | Specific Gravity |
| OC0055-23† | 55 Gallon – 15 deg with bolt-on top | 26 | 23 x 37 | 8″ | 1 1/2″ | 2.0 |
| OC0100-23 | 100 Gallon – 15 deg with bolt-on top | 36 | 23 x 63 | 8″ | 1 1/2″ | 2.0 |
| OC0145-36 | 145 Gallon – 15 deg with bolt-on top | 52 | 36 x 41 | 8″ | 2″ | 2.0 |
| OC0200-36 | 200 Gallon – 15 deg with bolt-on top | 58 | 36 x 53 | 8″ | 2″ | 2.0 |
| OC0250-36 | 250 Gallon – 15 deg with bolt-on top | 76 | 36 x 65 | 8″ | 2″ | 2.0 |
| OC0325-36 | 325 Gallon – 15 deg with bolt-on top | 92 | 36 x 82 | 8″ | 2″ | 2.0 |
| Part No. | Capacity | Weight | Dimensions | Lid | Fitting | Specific Gravity |
